Code GPU with CUDA

SIMT

NVIDIA GPU architecture

Back to contents

Hardware revisions

SM (shading model) – particular hardware implementation.

Latency vs Throughput architectures

Modern CPUs and GPUs are both multi-core systems.

• CPUs are latency oriented:
  • Pipelining, out-of-order, superscalar
  • Caching, on-die memory controllers
  • Speculative execution, branch prediction
  • Compute cores occupy only a small part of a die


• GPUs are throughput oriented:
  • 100s simple compute cores
  • Zero cost scheduling of 1000s or threads
  • Compute cores occupy most part of a die

SIMD – SIMT – SMT

Single Instruction Multiple Thread

• SIMD: elements of short vectors are processed in parallel. Represents problem as short vectors and processes it vector by vector. Hardware support for wide arithmetic.
• SMT: instructions from several threads are run in parallel. Represents problem as scope of independent tasks and assigns them to different threads. Hardware support for multi-threading.
• SIMT vector processing + light-weight threading:
  • Warp is a unit of execution. It performs the same instruction each cycle. Warp is 32-lane wide
  • thread scheduling and fast context switching between different warps to minimize stalls

SIMT

depth of Multi-threading × width of SIMD

1. SIMT is abstraction over vector hardware:
   • Threads are grouped into warps (32 for NVIDIA)
   • A thread in a warp usually called lane
   • Vector register file. Registers accessed line by line.
     A lane loads laneId’s element from register
   • Single program counter (PC) for whole warp
   • Only a couple of special registers, like PC, can be scalar
2. SIMT HW is responsible for warp scheduling:
   • Static for all latest hardware revisions
   • Zero overhead on context switching
   • Long latency operation score-boarding

SASS ISA

SIMT is like RISC

• Memory instructions are separated from arithmetic
• Arithmetic performed only on registers and immediates

SIMT pipeline

• Warp scheduler manages warps, selects ready to execute
• Fetch/decode unit is associated with warp scheduler
• Execution units are SC, SFU, LD/ST

Area-/power-efficiency thanks to regularity.

Vector register file

• While warp is resident on SM it occupies a portion of RF
• GPU's RF is 32-bit. 64-bit values are stored in register pair
• Fast switching costs register wastage on duplicated items
• Narrow data types are as costly as wide data types.

Size of RF depends on architecture. Fermi: 128 KB per SM, Kepler: 256 KB per SM, Maxwell: 64 KB per scheduler.

Dynamic vs static scheduling

• Static scheduling
  • instructions are fetched, executed & completed in compiler-generated order
  • In-order execution
  • in case one instruction stalls, all following stall too
• Dynamic scheduling
  • instructions are fetched in compiler-generated order
  • instructions are executed out-of-order
  • Special unit to track dependencies and reorder instructions
  • independent instructions behind a stalled instruction can pass it

Warp scheduling (cont)

Divergence & (re)convergence

Divergence: not all lanes in a warp take the same code path

• Convergence handled via convergence stack
• Convergence stack entry includes
  • convergence PC
  • next-path PC
  • lane mask (mark active lanes on that path)
• SSY instruction pushes convergence stack. It occurs before potentially divergent instructions
• <INSTR>.S indicates convergence point – instruction after which all lanes in a warp take the same code path

Divergent code example

 (void) atomicAdd( &smem[0], src[threadIdx.x] );

    /*0050*/        SSY 0x80;
    /*0058*/        LDSLK P0, R3, [RZ];
    /*0060*/    @P0 IADD R3, R3, R0;
    /*0068*/    @P0 STSUL [RZ], R3;
    /*0070*/   @!P0 BRA 0x58;
    /*0078*/        NOP.S;

Assume warp size == 4

Predicated & Conditional execution

• Predicated execution
  • Frequently used for if-then statements, rarely for if-then-else. Decision is made by compiler heuristic.
  • Optimizes divergence overhead.
• Conditional execution
  • Compare instruction sets condition code (CC) registers.
  • CC is 4-bit state vector (sign, carry, zero, overflow)

    IMAD R8.CC, R0, 0x4, R3;

  • No WB stage for CC-marked registers
  • Used in Maxwell to skip unneeded computations for arithmetic operations implemented in hardware with multiple instructions

Final words

• SIMT is RISC-based throughput oriented architecture
• SIMT combines vector processing and light-weight threading
• SIMT instructions are executed per warp
• Warp has its own PC and activity mask
• Branching is done by divergence, predicated or conditional execution
